Gas Unloading Pole

A two-system (one in use, one in reserve) intelligent gas unloading pole with emergency pull-off, explosion-proof, and leak-proof design for safe and reliable operation.

Product  Details

This gas unloading pole features dual systems configured as one active and one standby, ensuring continuous operation. Intelligent control enhances safety and reliability. Equipped with an emergency pull-off device, explosion-proof construction, and leak-proof sealing, it provides secure hydrogen transfer from tube trailers to the station.

Product Advantages

Dual-system design (one in use, one in reserve)
Intelligent control for safe and reliable operation
Emergency pull-off function
Explosion-proof and leak-proof

Gas Unloading Skid		Parameter Value
Applicable Gas		Hydrogen, Nitrogen
Pipe Material		SS316L/SS316
Pressure	Design Pressure	25 MPa
	Rated Working Pressure	20 MPa
	Pressure Test	27.5 MPa
	Tightness Test	25 MPa
Design Temperature		-20~60℃
Unloading Flow Rate（Nm3/hr）		1000
Number of Unloading Interfaces		2
Operating Voltage		DC 24V
