Separable Connector

It is applicable to connect extruding MV cables with Ring main cabinet unit , suitable for XLPE or EPR insulated cables with copper, aluminum or aluminum alloy conductors.

Features

I Easy Installation: no flame and heat required,no special tools required.
II Compact Design: suitable for narrow space.
III Free Installation direction: Products Mounting can be vertical , horizontal and any angle.
IV Operation Safety thinking: Anti-electrical shock design.

Standards:

IEC60502

IEC60840

EN50181

EN50180

match with the bushing complying with interface C EN50181/EN50180

Voltage Level:

3.6/6kV、6/10kV、8.7/15kV、12/20kV、18/30kV、19/33kV、21/35kV、26/35kV

Products specification：

Voltage （kV）	Insulation Diameter（mm）	Cross Section Area of Conductor （mm2）
3.6/6kV、6/10kV、8.7/15kV、12/20kV	22-40	50-400
18/30kV、19/33kV、21/35kV、26/35kV	26-46	50-500

It is applicable to connect extruding MV cables with Ring main cabinet unit , suitable for XLPE or EPR insulated cables with copper, aluminum or aluminum alloy conductors.
