Suitable for transmission and distribution system with rated voltage up to 0.6/1kV.
The low-voltage cable with shielding but without armoring has an additional shielding layer outside the insulation, which can effectively reduce external electromagnetic interference and ensure the stable transmission of signals.
Cables are offered accords with different standards, IEC, AS/NZS, NF C, IRAM, SANS, BS, DIN, AIEC, etc.
Conductor: Copper/aluminum wire, class 2 stranding
Number of Cores: 1, 2, 3, 4, 5, 3+1, 4+1, 3+2
Nominal Cross Sectional Area/mm2: 10-800
Insulation: Optional of Cross-Linked Polyethylene(XLPE), Polyvinyl Chloride(PVC)
Metallic screen: Optional of copper wire, copper tape, aluminum wire
Outer Sheath: Optional of Polyvinyl Chloride(PVC), Polyethylene(PE)
Max. continuous temperature in operation: 90℃
For XLPE insulated cable: 90℃
For PVC insulated cable: 70℃
Max. short-circuit temperature of the conductor (max. duration: 5 seconds): 250℃
Min. installation ambient temperature: 0℃
Permissible pulling force:
For copper conductor: 70N/mm2
For aluminum conductor: 40N/mm2
For aluminum alloy conductor: 55N/mm2
Permissible side pressure: 3000N/m
Permissible bending radius of cable during installation:
For single core cable: 20D
For multi-cores cable: 15D
(Note: D-out diameter of the cable)
It is commonly used in places with certain requirements for electromagnetic interference, such as computer network cabling, data transmission systems and the power supply lines for some precision instruments. In these scenarios, external electromagnetic interference may affect signal quality, and the shielding layer can reduce interference and ensure the accuracy and stability of signal transmission.
When the customer need special function cable, for example water-blocking, water proofing, lame retardant, fire resistant, anti-termites, anti-biting, laying in the river or in the sea, the construction should be further designed.
